Main specifications:

.Heating Zone : Upper 4 Zones/ Down 0 Zone

.Heating Zone Length : 1400mm

.Heating Method : Full Forced Hot Air Heating

.Warm-up time : 15min

.Cooling Method : Transverse Flow Forced Air Cooling

.Temperature control precision : ±1?

.PCB Max. Width : Mesh belt width 300mm

.Transmission Direction : Left ? right (right ? left optional)

.Conveyor Speed : 0-2000mm/min

.Power Supply : 3-phase 380V (220V optionnel) 50/60Hz

.Dimensions: 2500 × 612 × 1220 mm

.Weight : about 300Kg
