Aqueous based cleaning agent designed for spray and wipe cleaning of solder reflow ovens, wave soldering machines and stencil printing machines used in the electronics industry assembly
Characteristics ;
|
Parameter |
Value |
|
Clarity |
Clear |
|
Color |
Light Amber |
|
Odor |
Mild |
|
Flash Point, °C |
None to Boiling |
|
Boiling Point, °F/C |
105°C / 221°F |
|
Volatile Organic Compound |
299 g/L |
|
pH |
10 |
|
Specific Gravity |
1.06 @ 20°C |
|
Weight/gallon |
8.9 lb/gal |
|
Alkalinity Ratio |
Not Applicable |
|
Non-volatile Residue |
0.8% |
PPE equipment and accessories are required for handling and using the solvent - please refer to labeling safety requirements.
1. Concentration for application: must be used as delivered.
2. Processing temperature: ambient temperatures.
3. Ultrasonic treatment: Compatible when used in immersion with an ultrasonic cleaner.
4. Processing time: Depends on the part to be cleaned and the nature of the parts treated. Minimum 10 to 15 minutes - For excessive or sticky dirt, more time should be needed.
5. Rinsing: Rinse with water to avoid the presence of white residues. This residue is the Non-Volatile Residue.
6. If all the dirt has not been cleaned up after the process, start over from step one.
It is advisable to test the product on a small area before first use to ensure that it will not damage the surface of the treated part.
STORAGE: in the original container at temperatures between 5-50 ° C - Indoors in a dark, dry area in a sealed container
SHELF LIFE: Up to 5 years in original sealed packaging if storage requirements are met
HANDLING: Refer to the Material Safety Data Sheet
