The HCT-900 Hand Held Convection Tool offers a low cost, versatile rework solution for a wide variety of production and rework application challenges. It has a compact, robust design comprising of analog controls for both airflow and heat.

A closed loop feedback circuit controls the temperature allowing the desired temperature to be achieved and maintained regardless of changes in the volume of airflow.

Features and Benefits:

.Versatile hot air tool for soldering and desoldering applications

.Robust and compact design

.Analog controls for both airflow and heat

.Closed loop feedback circuit controls the temperature

.Unique low noise air pump (less than 45 db) provides precise airflow control

.Fully ESD compliant

Main features:

Versatile 900 W fast-heating hot air tool for soldering and desoldering applications

Max temperature of 600 °C (1112 °F)

Max airflow up to 120 l/m (4.2 cfm)

Digital controls for both airflow & temperature, for increased precision

On-the-fly manual mode _ quickly toggle between temperature and flowrate

Handpiece start/stop button & status light

Tool-less nozzle removal & replacement

ESD compliant

TUV certified, CE listed

Characteristics

System delivered with :

.HCT-910 Base Unit

.Hand-piece Cradle

.5.0 mm Ø Bayonet Nozzle

.Power Cord

Accessories (sold separately)

.HCT-910-HE-21Replacement Heater, 230 V Input

.HB-D25Nozzle, Bayonet, 2.5 mm Ø

.HB-D50Nozzle, Bayonet, 5.0 mm Ø

.HB-D100Nozzle, Bayonet, 10.0 mm Ø

.HB-D25-BBent Nozzle, Bayonet, 2.5 mm Ø

.HB-D50-BBent Nozzle, Bayonet, 5.0 mm Ø

.HB-STNozzle, Bayonet, Shrink Tube

HCT-910 Nozzles are compatible with legacy HCT-900 and HCT- 1000 series systems
