Specifications:

.Max dimensions PCB 610?350 mm;

.Min dimensions PCB 50?50 mm;

.Thickness PCB - 0,4 - 6 mm;

.Max frame size from 420?520 mm to 800?800 mm;

.Process repeatability -  25 micron (6 sigma);

.Field of view camera  -  10,24?6,4 mm;

.Adjustment range of PCB for stencil along axes   XY±7 mm, angle ±2 grade;

.The cycle time of the equipment at 1 PCB (without taking into account the time of printing and cleaning the stencil) - less than 7 seconds;

.The transition time from product to product is less than 5 minutes;

.Adjustable print speed from 0 to 200 mm/sec;

.Adjustable conveyor speed - to 1500 mm/sec;

.Adjustable drive pressure squeegee from 0,5 to 10 kg/cm2;

.Adjustable clearance separation of the stencil from the PCB after printing - 0,02 - 12 mm;

.Conveyor height - 900±40 mm;

.The direction of movement of the conveyor: from left to right, right to left, right to right, left to left;

.Overall dimensions of the equipment - 1140 (S) × 1400 (G) × 1480 (V) mm;

.Power supply -  220V±10%, 50/60 Hz, consumption - 3,3 kW;

.Air supply (compressed air supply) - 4-6 atm., hose 10 mm;

.Machine weight - 1200 kg.
